TODAAIR JS-P165 Wireless 1080P Indoor Smart Security Camera User Manual

1. محصول ختم شوview

The TODAAIR JS-P165 is a 1080P HD wireless indoor smart security camera designed for home surveillance. It features night vision, accurate motion detection, 135° viewing angle, and two-way audio communication. This camera connects via 2.4GHz Wi-Fi and supports local TF card storage as well as cloud storage options.

Image 1.1: TODAAIR JS-P165 Camera Features. This image illustrates the camera's key functionalities including 1080P HD resolution, 16.5ft/5m infrared night vision, cloud storage, motion detection, two-way audio, and support for up to 128GB TF cards. It also highlights the 135° wide-angle lens and the manual rotation capabilities of 180° vertically and 360° horizontally.

2. د بسته محتويات

مهرباني وکړئ د لاندې توکو لپاره په بسته کې وګورئ:

• TODAAIR JS-P165 Smart Security Camera
• د USB بریښنا کیبل
• د بریښنا اډاپټر
• د نصبولو لوازمات (پیچونه، دیوال لنگرونه)
• د کارن لارښود

۳. فزیکي برخې

Familiarize yourself with the camera's physical features and ports.

• د کیمرې لینز: Captures 1080P HD video.
• انفراریډ LEDs: Provides clear night vision up to 16.5ft (5m).
• مایکروفون: د دوه اړخیزه آډیو اړیکو او غږ کشف لپاره.
• سپیکر: د دوه اړخیزه آډیو اړیکو او خبرتیاو لپاره.
• USB پورټ: Connects the camera to the power adapter using the provided USB cable.
• د بیا تنظیم تڼۍ: Used to reset the camera to factory settings. Typically located near the USB port.
• د SD کارت ساکټ: Supports up to 128GB TF (Micro SD) card for local video storage.

4. د تنظیم کولو لارښود

4.1 فعالول

1. Connect the USB power cable to the camera's USB port.
2. د USB کیبل بل پای د بریښنا اډاپټر سره ولګوه.
3. د بریښنا اډاپټر د دیوال په یوه ساکټ کې ولګوئ. کیمره به فعاله شي او د LED څراغ سره به خپل حالت په ګوته کړي.

۳.۲ د اپلیکیشن ډاونلوډ او د حساب ثبتول

1. Download the 'Smart Life' or 'Tuya Smart' app from the Apple App Store or Google Play Store.
2. اپلیکیشن پرانیزئ او د نوي حساب لپاره راجستر کړئ یا که تاسو دمخه یو حساب لرئ نو ننوتل وکړئ.

۴.۳ اپلیکیشن ته د کیمرې اضافه کول

1. Ensure your mobile device is connected to a 2.4GHz Wi-Fi network. (5GHz Wi-Fi is not supported).
2. Open the app, tap '+' or 'Add Device'.
3. Select 'Security & Video Surveillance' > 'Smart Camera (Wi-Fi)'.
4. Follow the on-screen instructions to reset the camera (if necessary) and confirm the indicator light is blinking rapidly.
5. خپل د 2.4GHz Wi-Fi شبکې پټنوم دننه کړئ.
6. The app will generate a QR code. Hold your phone with the QR code approximately 6-8 inches (15-20 cm) in front of the camera lens until you hear a prompt.
7. Once connected, the camera's LED indicator will turn solid blue, and the camera will appear in your app's device list.

4.4 د کیمرې پورته کول

کیمره په یوه فلیټ سطحه کې کیښودل کیدی شي یا په دیوال یا چت کې نصب کیدی شي.

Image 4.1: Camera Dimensions and Mounting Options. This image displays the camera's dimensions (4.53 inches / 115mm height, 3.15 inches / 80mm width) and highlights the screw slots on the base for quick wall mounting.

1. د ټابلیټ ځای پرځای کول: Simply place the camera on any flat, stable surface.
2. د دیوال/چت نصب کول: Use the provided mounting accessories. Mark the desired position, drill holes, insert wall anchors, and secure the camera base with screws. Adjust the camera's angle manually as needed.

5. عملیاتي لارښوونې

5.1 ژوندی View او پلې بیک

Once connected, tap on the camera in the app to access the live video feed. You can view ریښتیني وخت footage and access recorded videos from the timeline if an SD card is inserted or cloud storage is active.

۴.۴ دوه اړخیزه آډیو

کیمره د دوه اړخیزو اړیکو لپاره یو جوړ شوی مایکروفون او سپیکر لري.

Image 5.1: Two-Way Audio Functionality. This image shows a scenario where a user can communicate through the camera using the two-way audio feature, allowing interaction with family members or pets remotely.

1. په ژوندۍ بڼه view interface, tap the microphone icon to speak through the camera.
2. د کیمرې له چاپیریال څخه د آډیو اوریدو لپاره د سپیکر آیکون باندې کلیک وکړئ.

۵.۳ د حرکت کشف او خبرتیاوې

The camera can detect motion and send real-time alerts to your phone.

Image 5.2: Motion Detection Alerts. This image demonstrates how the camera detects movement, such as a dog walking, and sends an immediate notification to the user's smartphone via the app.

1. په اپلیکیشن کې د کیمرې ترتیباتو ته لاړ شئ.
2. Enable 'Motion Detection' and adjust sensitivity levels as desired.
3. You will receive push notifications on your phone when motion is detected.

5.4 د شپې لید

کیمره په اتوماتيک ډول په ټیټ رڼا شرایطو کې انفراریډ د شپې لید ته بدلیږي.

Image 5.3: Night Vision and Motion Detection. This image illustrates the camera's ability to provide clear black-and-white footage in low-light conditions using infrared night vision, alongside its motion detection capabilities for enhanced security.

5.5 ثبتول او ذخیره کول

The camera supports both local storage via a TF card and optional cloud storage.

Image 5.4: Cloud and Local Storage Options. This diagram highlights the availability of USA server cloud storage (with data centers in Oregon and Virginia) and local storage via a maximum 128GB TF card, ensuring data privacy and flexible recording options.

1. د TF کارت ذخیره کول: Insert a formatted TF card (up to 128GB) into the SD card socket. The camera will automatically begin recording based on your settings (e.g., continuous, motion-triggered).
2. د بادل ذخیره کول: Subscribe to the cloud storage service through the app for secure, off-site video backup.

6. ساتنه

۴.۱ د لینز پاکول

To ensure clear image quality, regularly clean the camera lens with a soft, dry cloth. Avoid using harsh chemicals or abrasive materials.

6.2 د فرم ویئر تازه معلومات

Periodically check the app for available firmware updates. Keeping your camera's firmware up-to-date ensures optimal performance and security features. Follow the in-app instructions for any updates.

7. ستونزه حل کول

• کیمره آفلاین:
  • Check if the camera is powered on and the power adapter is working.
  • Ensure your Wi-Fi network is stable and the camera is within range.
  • کیمره د خلاصولو او بیا پلګ کولو سره بیا پیل کړئ.
  • If the issue persists, try resetting the camera and re-pairing it with the app.
• له وائی فای سره وصل نشی
  • Confirm your Wi-Fi network is 2.4GHz. The camera does not support 5GHz networks.
  • ډاډ ترلاسه کړئ چې په اپلیکیشن کې داخل شوی د وای فای پټنوم سم دی.
  • کیمره خپل وای فای روټر ته نږدې کړئ.
  • Reset the camera and try the pairing process again.
• د حرکت کشف خبرتیاوې نه دي ترلاسه شوي:
  • Check the motion detection settings in the app to ensure it's enabled and sensitivity is appropriate.
  • Verify that app notifications are enabled in your phone's settings.
  • ډاډ ترلاسه کړئ چې کیمره یو باثباته انټرنیټ اتصال لري.
• SD کارت نه ثبتوي:
  • Ensure the TF card is inserted correctly and is not full.
  • Format the TF card through the camera settings in the app.
  • Check if recording settings (e.g., continuous recording, motion-triggered recording) are enabled in the app.

8. مشخصات

9. تضمین او ملاتړ

9.1 د تضمین معلومات

This product comes with a standard manufacturer's warranty. Please refer to the product packaging or contact TODAAIR customer service for specific warranty terms and conditions.

9.2 د پیرودونکي ملاتړ

If you encounter any issues or have questions regarding your TODAAIR JS-P165 camera, please contact our customer support team. We are committed to providing professional after-sale service within 24 hours.

د اړیکو معلومات:

• بریښنالیک: support@todaair.com (بېلګهample email, please replace with actual if available)
• Webسایټ: TODAAIR Official Store on Amazon
