BuTure VAC VC60 Cordless Vacuum Cleaner User Manual

1. د خوندیتوب مهمې لارښوونې

مهرباني وکړئ د دې وسیلې کارولو دمخه ټولې لارښوونې په دقت سره ولولئ. دا لارښود د راتلونکي حوالې لپاره وساتئ.

• دا وسیله یوازې د کور د کارونې لپاره ده. په بهر یا لوند سطحو مه کاروئ.
• ماشومانو ته اجازه مه ورکوئ چې ویکیوم کلینر وکاروي. کله چې د ماشومانو سره نږدې کارول کیږي نو نږدې څارنه اړینه ده.
• اور مه اخلئ یا سوځیدونکي مایعات لکه ګازولین مه اخلئ، یا په هغه ځایونو کې مه کاروئ چیرې چې شتون ولري.
• هغه څه مه اخلئ چې سوځول یا سګرټ څکول وي، لکه سګرټ، ماچس، یا ګرمې.
• د دوړو کپ او فلټرونو پرته مه کاروئ.
• Turn off the appliance before connecting or disconnecting the motorized brush, extension tube, or other accessories.
• یوازې د جوړونکي لخوا وړاندیز شوي ضمیمې وکاروئ.
• ویکیوم کلینر په اوبو یا نورو مایعاتو مه ډوبوئ.
• که چیرې د چارج کولو کیبل خراب شوی وي، نو باید د تولید کونکي، د هغې د خدماتو اجنټ، یا ورته وړ اشخاصو لخوا بدل شي ترڅو د خطر څخه مخنیوی وشي.

2. د بسته محتويات

Carefully unpack all components and check against the list below. If any items are missing or damaged, contact customer support.

Image: All components included in the BuTure VAC VC60 package.

• 1 x Vacuum Cleaner Main Body
• 1 x Telescopic Extension Tube
• 1 x Electronic Brush for Soft and Hard Floors
• 3 x HEPA Filters (1 installed, 2 replacements)
• 1 x Scented Tablet Tray
• 1 x ګردي برش
• 1 x د کریویس وسیله
• 1 x د بیټرۍ کڅوړه
• 1 x چارجر
• 1 x Small Cleaning Tool
• 1 x وال ماونټ
• 1 x د کارونکي لارښود

3. مجلس او ترتیب

Follow these steps to assemble your BuTure VAC VC60 cordless vacuum cleaner.

1. د توسیع ټیوب ضمیمه کړئ: Insert the telescopic extension tube into the main body until it clicks securely into place.
2. د فرش برش سره وصل کړئ: Attach the electronic brush for soft and hard floors to the other end of the extension tube, ensuring it clicks firmly.
3. بیټرۍ نصب کړئ: Slide the battery pack into the designated slot on the main body until it locks. Ensure it is fully charged before first use.
4. اختیاري لوازم: For handheld use or specific cleaning tasks, attach the round brush or crevice tool directly to the main body or the extension tube.
5. د دیوال نصب کول: Choose a suitable location for the wall mount. Secure it to the wall using appropriate screws and anchors (not included). The vacuum can then be stored on the mount.

4. عملیاتي لارښوونې

Learn how to use your vacuum cleaner effectively.

۶.۱ د بریښنا فعالول/بندول او سکشن حالتونه

Image: OLED display indicating suction modes and battery status.

• پاور آن: Press the power button on the main body to turn on the vacuum cleaner. It will start in the default suction mode.
• سکشن تنظیم کړئ: Use the mode button to cycle through the three available suction levels:
  • ایکو موډ (۱۲ kPa): د سپکو پاکولو او اوږد چلولو وخت لپاره.
  • Mid Mode (25 kPa): د ورځني پاکولو دندو لپاره.
  • Max Mode (38 kPa): For deep cleaning and stubborn dirt.
• OLED ښودنه: The intelligent color OLED display shows the current battery level, selected suction mode, and provides intuitive instructions for troubleshooting if issues arise.
• بندول: د ویکیوم کلینر بندولو لپاره د بریښنا تڼۍ بیا فشار ورکړئ.

4.2 Using the Scented Tablet Tray

Image: The vacuum cleaner's aroma feature in action.

The VC60 includes a scented tablet tray to release a fresh fragrance during operation. Locate the tray, insert a scented tablet (one is included, additional tablets sold separately), and close the tray. The vacuum will then disperse a pleasant scent as you clean.

۷. چارج کول او بیټرۍ

Image: Removable battery with charging and runtime indicators.

• د بیټرۍ ظرفیت: The vacuum is equipped with a 7 x 2200 mAh lithium-ion battery.
• چارج کول: Connect the charger to the battery pack (either attached to the vacuum or removed). Plug the charger into a power outlet. The OLED display will indicate charging status.
• د چارج کولو وخت: بشپړ چارج معمولا 4-5 ساعته وخت نیسي.
• د چلولو وخت: Enjoy up to 55 minutes of cleaning performance on a single charge (in Eco mode). Runtime will vary based on the selected suction mode and surface type.
• د بیټرۍ لرې کول: The battery is removable for convenient charging or replacement. Press the battery release button and slide the battery out.

6. ساتنه

منظم ساتنه غوره فعالیت تضمینوي او ستاسو د ویکیوم کلینر عمر اوږدوي.

۶.۱ د کثافاتو د ډبې خالي کول

Empty the 1.5-liter dustbin regularly, especially when the MAX fill line is reached, to maintain strong suction.

1. ډاډ ترلاسه کړئ چې خلا بنده ده.
2. Press the dustbin release button and remove the dustbin from the main body.
3. Position the dustbin over a trash can and press the bottom release latch to open the lid and empty the contents.
4. Close the lid and reattach the dustbin to the main body until it clicks.

6.2 د فلټرونو پاکول

Image: Multi-cone filtration system with HEPA filter.

The VC60 features a high-quality filtration system, including HEPA filters, designed to capture over 99.98% of fine particles. Clean filters regularly to prevent clogging and maintain suction power.

1. لکه څنګه چې پورته تشریح شوي، د کثافاتو ډبې لرې کړئ.
2. د فلټر اسمبلۍ وګرځوئ او د کثافاتو له ډسټری څخه یې وباسئ.
3. Separate the HEPA filter and other filter components.
4. Tap off loose dirt. Rinse the filters under cold running water until the water runs clear. Do not use detergent.
5. Allow all filter components to air dry completely for at least 24 hours before reassembling and placing them back into the dustbin. Do not use a dryer or heat to dry.
6. Replace HEPA filters every 3-6 months, or as needed, for optimal performance.

۶.۳ د برش رول پاکول

Image: Anti-tangle V-shaped brush roll design.

The V-shaped brush roll and comb-like structure are designed to minimize hair tangles. However, occasional cleaning is recommended.

1. ډاډ ترلاسه کړئ چې ویکیوم بند شوی او د بریښنا سرچینې څخه منقطع شوی دی.
2. Locate the brush roll release tab on the side of the floor brush head.
3. Open the tab and remove the brush roll.
4. Use the small cleaning tool provided to cut and remove any tangled hair or debris from the brush roll.
5. Clean the brush roll housing.
6. Reinsert the brush roll and close the release tab until it clicks.

7. ستونزه حل کول

If you encounter any issues with your vacuum cleaner, refer to the following table for common problems and solutions. The OLED display may also provide diagnostic messages.

8. مشخصات

Technical details for the BuTure VAC VC60 Cordless Vacuum Cleaner.

۷. تضمین او د پیرودونکو ملاتړ

BuTure VAC provides a professional after-sales service and support team. For warranty information, technical assistance, or any questions regarding your VC60 cordless vacuum cleaner, please contact BuTure VAC customer support through the retailer where the product was purchased or refer to the official BuTure VAC webد تماس جزیاتو لپاره سایټ.

مهرباني وکړئ د تضمین ادعاګانو لپاره د پیرود ثبوت وساتئ.
