د جوکي MO-1200QVP د توپیر فیډ سرجر لارښوونې لارښود

1. پیژندنه

This manual provides essential instructions for the safe and efficient operation, setup, and maintenance of your Juki MO-1200QVP Differential Feed Serger. Please read this manual thoroughly before using the machine to ensure proper function and to prevent damage or injury. Keep this manual in a safe place for future reference.

2. د خوندیتوب لارښوونې

• Always disconnect the machine from the power supply before cleaning, oiling, or performing any maintenance.
• Keep fingers away from all moving parts, especially the needles and cutting blades, during operation.
• یوازې د ټاکل شوي بریښنا رسولو حجم وکاروئtage.
• Do not operate the machine if the power cord is damaged or if the machine is not functioning correctly.
• ماشین د ماشومانو د لاسرسي څخه لرې وساتئ.
• Ensure adequate lighting in your work area.

3. محصول ختم شوview

Familiarize yourself with the main components and controls of your Juki MO-1200QVP serger.

شکل 3.1: مخکی view of the Juki MO-1200QVP Differential Feed Serger, showing the main body, tension dials, and needle area.

شکل 3.2: شاته view of the serger, illustrating the thread spool holder and power input port.

شکل 3.3: تفصيلي view of the color-coded tension dials, crucial for stitch formation.

شکل 3.4: The looper area with the front cover open, revealing the internal threading paths and a helpful diagram.

شکل 3.5: Close-up of the needle bar, presser foot, and cutting blades.

شکل 3.6: اړخ view displaying the differential feed adjustment dial and stitch length control.

4. ترتیب کول

4.1 پیک کول

Carefully remove the serger from its packaging. Retain all packing materials for future transport or storage. Ensure all accessories listed in the packing list are present.

4.2 د بریښنا نښلول

1. ماشین په یوه مستحکم او هموار سطحه کې کیږدئ.
2. Connect the foot controller plug to the machine's foot controller jack.
3. Insert the power cord into the machine's power input port (refer to Figure 3.2).
4. د بريښنا تار په مناسبه بريښنايي دستګاه کې ولګوئ.

4.3 Thread Spool Installation

Place the thread spools onto the spool pins on the thread stand (refer to Figure 3.2). Ensure the thread unwinds smoothly from each spool.

۵.۳ د ماشین تار کول

Accurate threading is critical for proper serger function. Follow the color-coded threading paths indicated on the machine and in Figure 3.4. It is recommended to thread the loopers first, then the needles.

1. Raise the presser foot and turn the handwheel to raise the needles to their highest position.
2. د ماشین مخکینۍ او اړخ پوښونه خلاص کړئ.
3. Follow the color-coded guides for each thread, starting with the upper looper, then the lower looper, and finally the right and left needles.
4. Ensure each thread passes through all tension discs and guides correctly.
5. Close the covers securely after threading.

5. عملیاتي لارښوونې

5.1 Basic Serging

1. د بریښنا سویچ چالان کړئ.
2. Place the fabric under the presser foot, aligning the edge with the cutting blade.
3. د فشار پښه ښکته کړئ.
4. Gently press the foot controller to begin serging. Guide the fabric smoothly.

۵.۲ د تار د فشار تنظیمول

The Juki MO-1200QVP features individual tension dials for each thread (refer to Figure 3.3). Adjust these dials to achieve a balanced stitch. A balanced stitch will have the needle threads meeting at the edge of the fabric and the looper threads interlocking smoothly.

• زیاتوالیasing Tension: ډایل لوړ شمېرې ته واړوئ.
• ډیکرasing Tension: ډایل ټیټ شمیرې ته واړوئ.

۴.۳ د فیډ توپیري سمون

The differential feed mechanism (refer to Figure 3.6) allows you to adjust the feeding ratio of the front and rear feed dogs. This is essential for preventing stretching on knit fabrics or gathering on fine fabrics.

• Normal Feed (N): For most woven fabrics.
• Gathering (1.5 - 2): For intentionally gathering fabric.
• Stretching Prevention (0.7 - 0.9): For preventing stretching on knit fabrics.

5.4 Stitch Length and Width

Adjust the stitch length and cutting width using the dedicated dials on the machine (refer to Figure 3.6 for stitch length). Refer to the machine's markings for recommended settings for various stitch types.

6. ساتنه

6.1 پاکول

Regular cleaning is vital for optimal performance. Use a small brush and vacuum cleaner to remove lint and thread scraps from the looper area, under the needle plate, and around the feed dogs. Always disconnect power before cleaning.

۵.۲ غوړول

Apply a small drop of high-quality sewing machine oil to the designated oiling points as indicated in the detailed diagram within your machine's internal cover or the full printed manual. Oiling should be done periodically based on usage.

۷.۳ د ستنې بدلول

Use only 130/705H type needles. Replace needles regularly, especially if they become bent, dull, or if you experience skipped stitches. Ensure the flat side of the needle faces the back of the machine when inserting (refer to Figure 3.5).

7. ستونزه حل کول

• پریښودل شوي ډنډونه: Check needle insertion, ensure it's not bent or dull. Re-thread the machine carefully.
• د تار ماتېدل: Verify correct threading, check tension settings, ensure thread quality, and inspect for burrs on thread guides.
• نا مساوي بندونه: Adjust differential feed settings according to fabric type. Check tension balance.
• ماشین نه پیل کیږي: Ensure power cord is securely plugged in, power switch is on, and foot controller is connected.

د دوامداره ستونزو لپاره، د وړ خدماتو تخنیکین سره مشوره وکړئ.

8. مشخصات

9. تضمین او ملاتړ

For information regarding warranty coverage, service, or technical support, please refer to the warranty card included with your product or visit the official Juki webسایټ. د پیرود ثبوت په توګه د پیرود رسید وساتئ.
