1. پیژندنه
This manual provides essential information for the safe and proper operation, setup, and maintenance of your Marklin 37973 HO Mikado Union Pacific Railroad (UP) Steam Locomotive. Please read this manual thoroughly before using the model to ensure optimal performance and longevity.
Image: Marklin 37973 HO Mikado Union Pacific Railroad (UP) Steam Locomotive with its tender, viewله اړخه ایډ، شوکasing its detailed black finish and 'UNION PACIFIC' lettering on the tender.
2. د خوندیتوب معلومات
تل د خوندیتوب لاندې احتیاطي تدابیر په پام کې ونیسئ:
- This product is a model and not a toy. It is intended for adult collectors and is not suitable for children under 14 years of age due to small parts and potential for injury.
- Keep the model away from water and moisture to prevent electrical damage.
- Do not operate the model near flammable materials.
- Ensure your power supply unit is compatible with Marklin HO systems and is properly grounded.
- د هر ډول ساتنې یا سمون ترسره کولو دمخه بریښنا قطع کړئ.
- ماډل په احتیاط سره اداره کړئ ترڅو نازکو برخو ته زیان ونه رسوي.
3. د بسته محتويات
Carefully unpack the box and verify that all components are present. The package should contain:
- Marklin 37973 HO Mikado Union Pacific Railroad (UP) Steam Locomotive
- Matching Tender (Coal Car)
- د لارښود لارښود (دا سند)
- Any additional small parts or accessories (e.g., detail parts, coupling components)
Image: The packaging box for the Marklin 37973 HO Mikado Union Pacific Railroad (UP) Steam Locomotive, featuring the Marklin logo and model number.
If any items are missing or damaged, please contact your retailer or Marklin customer support.
4. ترتیب کول
۳.۲ د لارې چمتووالی
Ensure your HO scale track is clean, properly assembled, and free of obstructions. For digital operation, ensure your track is connected to a compatible Marklin digital control unit.
4.2 Placing the Locomotive on the Track
- Carefully lift the locomotive by its body, avoiding delicate details.
- Align the wheels of the locomotive with the rails.
- Gently lower the locomotive onto the track, ensuring all wheels are properly seated on the rails.
4.3 Connecting the Tender
The tender (coal car) connects to the locomotive via a drawbar and electrical coupling. Carefully align the drawbar and push the tender towards the locomotive until the coupling engages. Ensure the electrical contacts are securely connected.
4.4 Digital System Connection
If using a Marklin digital system, ensure your control unit is powered on and the locomotive's address is correctly set. Refer to your digital control unit's manual for specific instructions on adding new locomotives.
5. چلول
5.1 بنسټیز کنټرولونه
Using your Marklin digital control unit:
- د سرعت کنټرول: Use the speed dial or buttons to increase or decrease the locomotive's speed. Start slowly to observe its movement.
- د لوري بدلون: Press the direction button to reverse the locomotive's direction.
5.2 Function Controls
The Marklin 37973 locomotive may feature various digital functions. Consult your digital control unit's manual and the locomotive's specific function list for details. Common functions include:
- Headlights/Taillights: Typically controlled by a function button (e.g., F0).
- د غږ دندې: If equipped, various steam locomotive sounds (e.g., whistle, bell, steam chuffs) can be activated via function buttons.
- Smoke Generator: If equipped and filled with smoke fluid, a function button may activate the smoke unit.
5.3 Running the Train
Always operate your model train on a clean track. Avoid excessive speed, especially on curves or through turnouts, to prevent derailments. Observe the locomotive's performance and listen for any unusual noises.
6. ساتنه
Regular maintenance ensures the longevity and smooth operation of your locomotive.
6.1 پاکول
- څرخونه: Periodically clean the locomotive's wheels and the track rails with a soft, lint-free cloth or a specialized track cleaning tool. Dirt and grime can impair electrical contact and running performance.
- بدن: Use a soft brush or cloth to gently remove dust from the locomotive's body. Avoid using harsh chemicals or abrasive materials.
6.2 غوړول
Refer to the detailed diagrams in the original Marklin documentation for specific lubrication points. Generally, a small amount of specialized model train oil or grease should be applied to:
- Axle bearings
- Gear teeth (use grease)
- Connecting rods and valve gear (very sparingly)
Do not over-lubricate, as excess oil can attract dust and dirt.
انځور: لاندې view of the Marklin 37973 HO Mikado locomotive and tender, showing the wheels, electrical contacts, and chassis details relevant for maintenance.
6.3 ذخیره کول
کله چې په کارولو کې نه وي، لوکوموټیو په خپل اصلي بسته بندۍ یا محافظتي پوښ کې په وچ، دوړو څخه پاک چاپیریال کې وساتئ، د مستقیم لمر وړانګو او سختې تودوخې څخه لرې.
7. ستونزه حل کول
If you encounter issues with your locomotive, try the following solutions:
| ستونزه | احتمالي لامل | د حل لاره |
|---|---|---|
| لوکوموټیو حرکت نه کوي. | No power to track; dirty track/wheels; poor electrical contact; incorrect digital address. | Check power supply; clean track and wheels; ensure locomotive is properly seated on track; verify digital address. |
| څراغونه کار نه کوي. | Function not activated; damaged bulb/LED; poor electrical contact. | Activate light function (e.g., F0); check for visible damage; ensure good track contact. |
| لوکوموټیو په بې نظمه توګه روان دی. | Dirty track/wheels; mechanical obstruction; insufficient lubrication. | Clean track and wheels; check for debris in mechanism; apply lubrication as per maintenance section. |
| Derailments occur frequently. | Improper track alignment; excessive speed; damaged wheels/trucks. | Inspect track for proper alignment; reduce speed, especially on curves; check wheels for damage. |
If the problem persists, contact Marklin customer support or a qualified service technician.
8. مشخصات
- د ماډل شمیره: 37973
- پیمانه: HO (۱:۸۷)
- ډول: Steam Locomotive with Tender
- Railroad: Union Pacific Railroad (UP)
- بریښنا سیسټم: Marklin AC (Digital)
- لومړی شتون لري: 2024/08/19 (as per Amazon.co.jp)
9. تضمین او ملاتړ
For information regarding warranty coverage, service, or technical support, please refer to the official Marklin website or contact your authorized Marklin dealer. Keep your proof of purchase for warranty claims.
Official Marklin Webسایټ: www.marklin.com
